Description
This new Bayview lever series is about half the cost of our solid cast square rosette collections, and looks great in any home.
Features
- Locked or unlocked by key outside or turn-piece inside.
- All metal components with inner anti-pick shield.
- Door Prep - Crossbore 2 1/8", Edge Bore 1", Latch Face 1" x 2 1/4"
- Strike-Full lip radius corner standard.
- Latch-1/2" throw bolt. Radius corner face plate standard
- Latch-1/2" throw bolt. Radius corner face plate standard
Specifications
- Handle Orientation: Non-handed
- Keyway Type: 5 pin KW1 keyway
- Projection: 2 3/8"
- Backset: 2 3/8" or 2 3/4" backset adjustable
- Door Thickenss: 1 3/8" to 1 3/4"
